| EK6 10 | EK6 20 | EK6 60 | EK6 150 | EK6 300 | EK6 400 | EK6 450 | EK6 600 | EK6 800 | EK6 2500 | EK6 4500 | EK6 9500 | ||||||||||||||||||||||
| 型号 | EK6 10 A | EK6 10 B | EK6 10 C | EK6 20 A | EK6 20 B | EK6 20 C | EK6 60 A | EK6 60 B | EK6 60 C | EK6 150 A | EK6 150 B | EK6 150 C | EK6 300 A | EK6 300 B | EK6 300 C | EK6 400 A | EK6 400 B | EK6 400 C | EK6 450 A | EK6 450 B | EK6 450 C | EK6 600 A | EK6 600 B | EK6 600 C | EK6 800 A | EK6 800 B | EK6 800 C | EK6 2500 A | EK6 2500 B | EK6 4500 A | EK6 4500 B | EK6 9500 A | EK6 9500 B |
| 额定扭矩(Nm) | 12.6 | 16 | 4 | 17 | 21 | 6 | 60 | 75 | 20 | 160 | 200 | 42 | 325 | 405 | 84 | 410 | 520 | 90 | 530 | 660 | 95 | 700 | 840 | 150 | 950 | 1,100 | 240 | 1,950 | 2,450 | 5,000 | 6200 | 10,000 | 12,500 |
| 孔径范围(mm) | 6-16 | 6-16 | 6-16 | 8-24 | 8-24 | 8-24 | 12-32 | 12-32 | 12-32 | 19-35 | 19-35 | 19-35 | 20-45 | 20-45 | 20-45 | 25-50 | 25-50 | 25-50 | 28-55 | 28-55 | 28-55 | 30-70 | 30-70 | 30-70 | 32-80 | 32-80 | 32-80 | 40-95 | 40-95 | 50-130 | 50-130 | 60-170 | 60-170 |
| 外径(mm) | 32 | 32 | 32 | 43 | 43 | 43 | 56 | 56 | 56 | 66.5 | 66.5 | 66.5 | 82 | 82 | 82 | 95 | 95 | 95 | 102 | 102 | 102 | 120 | 120 | 120 | 136.5 | 136.5 | 136.5 | 160/159 | 160/159 | 225/208 | 225/208 | 290/285 | 290/285 |
| 标准转速(rpm) | 20,000 | 20,000 | 20,000 | 19,000 | 19,000 | 19,000 | 14,000 | 14,000 | 14,000 | 13,000 | 13,000 | 13,000 | 10,000 | 10,000 | 10,000 | 9,500 | 9,500 | 9,500 | 9,000 | 9,000 | 9,000 | 6,800 | 6,800 | 6,800 | 4,000 | 4,000 | 4,000 | 3,500 | 3,500 | 3,000 | 3,000 | 2,000 | 2,000 |
| 总长度(mm) | 42 | 42 | 42 | 56 | 56 | 56 | 64 | 64 | 64 | 76 | 76 | 76 | 96 | 96 | 96 | 107 | 107 | 107 | 110 | 110 | 110 | 121 | 121 | 121 | 138 | 138 | 138 | 177 | 177 | 227 | 227 | 282 | 282 |
